Skyjack Vertical Mast Lift SJ12
| Skyjack vertical mast lifts offer an easy to service, low maintenance design in a compact and versatile package. These are zero emission, compact machines with low floor loading have the ability to go on elevators, making them ideal for multi-level job sites. |
- DC Motor controller
- Drivable at full height
- Variable speed, front two wheel hydraulic drive
- Zero inside turning radius
- Dual holding brakes
- Proportional controls
- 20” (0.51 m) Traversing platform
- 24V DC Power source
- Low voltage battery protection
- 30% Gradeability
- Solid rubber, non-marking tires
- Pothole protection system
- 110V AC Outlet at platform with GFI
- 28 mph Wind rating (12.5 m/s)
- Tilt alarm with drive & lift cut-out
- All motion audible alarm
- Lanyard attachment points
- Operator horn
- Lift rings/tie downs
- Chain entrance
- Relay based control system
- SKYCODEDTM color coded and numbered wiring system
- Telematics ready
- 2 Year Gold Leaf Warranty (5 year structural warranty)
- Light duty pipe rack
- Tool tray
- Florescent tube carrier
- Dual flashing lights
- AGM Batteries
- Full height spring hinged gate
- Saloon gate
- Bio oil
- Shroud-style control box guard
- Non destructive testing
- ELEVATE telematics package
- Warranty Options (3 year or 5 year plans available)
- Secondary Guarding Lift Enable (SGLE) w/ shroud
Model:SJ12, Work Height (in.): 18'
Featured Attribute:N/A, Fuel Type:Battery, Raised Platform Height (ft.): 12', Lowered Platform Height (ft.):18", Overall Width (in.):30.5”, Overall Length (in.):54", Platform Capacity at Lift Height (lb) (in.) : 500 Overall, Platform Lift Time (sec):16, Platform Lower Time (sec): 14, Ground Clearance (Collapsed) (in.): 0.63", Ground Clearance (Lifted) (in.):2.1", Wheelbase (in.):N/A, Max Travel Speed (Lowered) (mph):2.5, Max Travel Speed (Lifted) (mph): 0.5, Max Gradeability (%):30%, Turn Radius Inside (deg): 0,Turn Radius Outside (deg): 55", Number of Mast Stages: N/A, Electrical Voltage: N/A, Max Drive Height: Full Height
Model:SJ12
