Toyota 80V Electric Pneumatic Forklift
| Want to maintain an all-electric fleet, but need a rugged, outdoor solution? Look no further than Toyota’s 80V Electric Pneumatic Forklift. These electric powerhouses combine the power, durability, and reliability of internal combustion trucks with the ergonomics and speed of electric forklifts. With a capacity ranging from 5,000-17,500 lb., these machines are ready to tackle any challenge, whether you’re operating indoors or outdoors. |
80V ELECTRIC PNEUMATIC FORKLIFT
|
Model
|
Load Capacity (lbs.)
|
Max Travel Speed Full Load (MPH)
|
Max Gradeability Full Load (%)
|
Basic Right Angle Stack (in.)
|
|
05-9FBMK20T
|
4,000
|
11.8
|
23 - 31
|
104.1
|
|
05-9FBM25T
|
5,000
|
11.8
|
19 - 29
|
110
|
|
05-9FBMK25T
|
5,000
|
11.8
|
20 - 29
|
104.1
|
|
05-9FBH25T
|
5,500
|
11.8
|
18 - 29
|
110.6
|
|
8FB30
|
6,000
|
8.7
|
11 - 19
|
106.1
|
|
05-9FBM30T
|
6,000
|
11.8
|
17 - 29
|
110.8
|
|
05-9FBMK30T
|
6,000
|
11.8
|
17 - 29
|
105.4
|
|
05-9FBH30T
|
6,500
|
11.8
|
16 - 29
|
111.5
|
|
8FBJ35
|
7,000
|
8.1
|
9 - 17
|
109.1
|
|
05-9FBM35T
|
7,000
|
11.8
|
15 - 29
|
111.8
|
|
05-8FBM40T
|
8,000
|
11
|
11.3 - 25
|
120.5
|
|
05-8FBM45T
|
9,000
|
11
|
9.5 - 24
|
121.1
|
|
05-8FBM50T
|
11,000
|
11
|
8.8 - 23
|
126.5
|
|
9FBM60T
|
13,000
|
11
|
7 - 19
|
146
|
|
9FBM70T
|
15,500
|
11
|
6 - 18
|
146.5
|
|
9FBH80T
|
17,500
|
10
|
5.2 - 16
|
|
|
9FBM80T
|
17,500
|
11
|
5.6 - 16
|
152
|
SUPPORT
- System of Active StabilityTM (SAS)
- Active control rear stabilizer
- Active mast function controller
- Operator presence sensing system (OPSS)
- Manual return to neutral
- Wet disc brake system
- Key lowering interlock
- Toyota Operator Restraint System (ORS)
- Overhead guard protector
- All metal, rugged exterior
PERFORMANCE
- AC drive system
- AC hydraulic lift system
- Maximum speed limiter
- Diagnostic code display
- Power select functions (S.P.H.)
- 3-way hydraulic control valve2
- 4-way valve3
- Accel-off function
- Three forms of energy regeneration
- Coast control
- Plug braking
- Foot braking
- LCD digital multifunction display
- Time & date
- Speedometer
- Multifunction hour meter
- Battery capacity indicator
- Over discharge warning (lift interrupt)
- Parking brake indicator
- Low speed setting switch
- Direction indicator
BODY/EXTERIOR DESIGN
- Wide view 2-stage mast (V)
- Punched plate entry/exit step
- 48” load backrest extension
- Treaded solid pneumatic tires
- Wide view carriage bars
- ORS vinyl full-suspension sea
- Retractable non-cinching seat belt
- Wide-opening battery hood
- Lateral battery exchange
- Bolt-on overhead guard
- Floating driver compartment
- Shockless landing lift
- Drive unit protector
OPERABILITY & ERGONOMICS
- Full hydraulic power steering2
- Electric power steering (EPS)3
- Large operator assist grip2
- Dual assist grips3
- SAS automatic fork leveling control
- Electric directional shift control
- 11.8” diameter two-spoke steering wheel
- Seat-mounted mini-lever hydraulic controls
- Heavy-duty non-slip floor mat
- Various storage compartments
- Automatic parking brake
- Wide brake pedal
- Adjustable tilt steering column
- Direction switch on armrest
- Strategically configured instrument display
- Paper clamp on hood
- Wide foot space from accelerator pedal to hood
- Steering knob
- Synchronized steering
SERVICEABILITY
- Easy access no-tools floorboard and side panels
- Planned maintenance indicator
- Easy access controllers
- CAN-Bus controller wiring
- Battery compartment hood assist
- Fanless controllers cooling system
Model:9FB, Tire Type: Pneumatic
Featured Attribute:Electric, Power/Fuel Type: Battery, Electrical System Voltage: 80V Horsepower (hp): 2x 28.4
