JLG R2632 Electric Scissor Lift

JLG R2632 Electric Scissor Lift

R Series electric scissor lifts are a rental-ready solution for all types of job sites. Offering greater affordability, reliability and serviceability, these scissor lifts have fewer parts and all-steel swing-out component trays. Their compact dimensions are ideal for confined spaces. Plus, the improved battery charger reduces guesswork by informing you on how your batteries are performing.

•Reach More in Difficult Conditions: Industry-exclusive outdoor rating for use up to 21 ft
•Tackle Demanding Terrain: Active pothole protection provides increased ground clearance
•Meet the Highest Standards: Complies with A92.20 ANSI regulations
•Fit Through Standard Doorways: Ability to pass through single doorways gives you more access site-wide

Featured Information

Product Badge:
Aerial Work Platforms
Price Link:
Request a Quote
Phone:
(763) 425-9066
Condition:
New
Location:
Brooklyn Park, MN
Location:
Byron, MN
Specification Tab:
true
Operational Tab:
true
Promotions:
true
Financing:
https://www.commercialcreditapps.com/BusinessIQ/credec/caps/pla/loadAppInternalPLAPage?addEditFlag=A&appTemplateId=dZwGGY%2ByrR7r%2B0FeNDXmlw%3D%3D&appTemplateToken=2710
Featured Info:
true
Inventory Form:
true
Featured Attributes Tab:
true
Power Source:
Battery
Manufacturer:
JLG
Brochure:
https://atlastoyota.com/asset/61ddd84e8ca51
SKU:
R2632

Specifications and Operational Information

Condition
New
Manufacturer
JLG
Model
R2632
Work Height (in.)
31 ft 6 in.
Featured Attribute
Electric
Fuel Type
Electric
Raised Platform Height (ft.)
25 ft 6 in.
Lowered Platform Height (ft.)
3 ft 8 in.
Overall Width (in.)
2 ft 8 in.
Overall Length (in.)
7 ft 10 in.
Platform Capacity at Lift Height (lb) (in.)
507
Platform Lift Time (sec)
32
Platform Lower Time (sec)
24
Ground Clearance (Collapsed) (in.)
4
Ground Clearance (Lifted) (in.)
N/A
Wheelbase (in.)
6 ft 2 in.
Max Travel Speed (Lowered) (mph)
2.2
Max Travel Speed (Lifted) (mph)
0.6
Max Gradeability (%)
25
Turn Radius Inside (deg)
0
Turn Radius Outside (deg)
7 ft 4 in.
Number of Mast Stages
N/A
Electrical Voltage
4 x 6V
Max Drive Height
21 ft
