Genie Runabout Vertical Mast Lift
|
Genie® Runabout® GR™-12 lifts are compact, low-weight machines that increase productivity on the job. Efficient operation and convenient setup these Genie Runabout lifts are ideal for warehousing, stock-picking, transporting, inventory management and general maintenance. The Genie® Runabout® GR-26J™ lift is a jib machine that offers outreach capability to get virtually any job done. A 140° rotating jib and 350° non-continuous hydraulic turntable allows for exceptional range of motion and precise positioning. These capabilities combined with the efficient electric drive motors and a low machine weight make the Genie Runabout GR-26J lift the solution for hard-to-reach jobsite needs. |
VERTICAL MAST LIFT
|
Model
|
Working Height (m)
|
Capacity (kg)
|
Collapsed Height (m)
|
Machine Width (cm)
|
|
GR-12
|
5.45
|
227
|
1.78
|
75 cm
|
|
GR-15
|
6.47
|
227
|
1.78
|
75 cm
|
|
GR-20
|
8.02
|
159
|
1.98
|
80 cm
|
|
GR-26J
|
9.90
|
200
|
1.99
|
0.99 m
|
Measurements
- GR-15
- 20 ft 8 in (6.52 m) working height
- 14 ft 8 in (4.52 m) platform maximum height (indoor)
- 11 ft 1 in (3.4 m) platform restricted (outdoor) height
- Up to 500 lbs (227 kg) lift capacity
Productivity
- Standard platform with sliding midrail
- Auxiliary platform lowering
- Patented rigid mast system
- Compact base 29.5 x 53 in
- (.75 m x 1.35 m) (GR™-12, GR™-15 only)
- Ground clearance 2.5 inches (stowed)
- SmartLink™ dual zone control system
- Battery charge indicator
- On-board diagnostic system
- AC power to platform
- Descent and tilt alarm
- Zero inside turning radius
- Dual wheel brakes
- Hydraulic brake release
- Pothole protection
- Productivity (continued)
- Hinged rear ABS covers for easy access to all major electrical and hydraulic components
- Tie down attachment points
- Overhead crane attachment point
- Large forklift pockets access
- Non-marking solid tires
- Motion alarm
- Dual LED flashing beacons
- Proportional drive and lift
- Load sense
- Platform control guard
- 20 in (.51 m) extension platform with sliding midrail
- 20 in (.51 m) extension platform with gate
- Lift Guard™ Contact Alarm
- Platform control guard
- Fluorescent tube caddy**
- Automotive horn
- EE Certification*
- Biodegradable hydraulic oil
- Drive cutout while charging
- 10 ft retractable charging cord*
Power
- 24V (four 6V 225 Ah batteries)
- 800 watt, 24 V inverter (120-230V AC/50-60 Hz)
- AGM maintenance-free batteries
Model:Vertical Mast Lift
Featured Attribute:N/A, Fuel Type:Electric
